| Image Sensor |
1/2.5" High-resolution CMOS Sensor |
| Resolution |
5MP |
| Effective Pixels |
2608(H)*1952(V) |
| Compression |
H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG |
| TV System |
PAL/NTSC |
| Electronic Shutter Time |
Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec |
| Minimun Illumination |
0.01Lux |
| S/N Ratio |
≥52dB |
| Scanning System |
Progressive |
| Video Output |
Network |
| Reset Button |
Optional |
| Lens |
| Focus Length |
2.8-12mm |
| Focus Control |
Manual |
| Lens Type |
Varifocal |
| Pixels |
5MP |
| Night Vision |
| Infrared LED |
42µ x 4PCS |
| Infrared Distance |
30M |
| IR Status |
Auto Control |
| IR Power On |
Auto Control |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP |
| ONVIF |
Support ONVIF 2.4 |
| P2P |
YES, Support QR Code |
| POE |
Optional/Internal, Support IEEE 802.3af |
| Video Delay |
0.3S (Within the Lan) |
| Main Stream 1 |
2592*1944@20fp |
| 2560*1920@20fp |
| Main Stream 2 |
2560*1440@25fp |
| Main Stream 3 |
1920*1080@30fps |
| 1280*720@30fps |
| Sub Stream 1 |
720*480@15fps |
| 720*480@30fps |
| IE Brower |
IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53),
Mac Safari(lower than version 12) |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| Camera Features |
| Day/Night |
Color/ B&W (IR-CUT ) |
| Image Config |
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance,
FLK(Flicker Control) |
| Corridor Pattern |
Support |
| BLC |
Support |
| WDR |
DWDR: 50dB |
| Motion Detection |
Support |
| Privacy Masking |
3 Rectangular Zone |
| Recording Mode |
NVR/CMS/Web |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands,Czech, Vietnamese |
| Interface |
| Audio |
Optional |
| SD Card Slot |
Optional, Support Max 512GB |
| RS485 |
/ |
| General |
| Housing |
Metal ,IP67 |
| Anti-cut Bracket |
Optional |
| IR Cut Filter |
YES |
| Operation Temperature |
-20℃ ~ +60℃ RH95% Max |
| Storage Temperature |
-20℃ ~ +60℃ RH95% Max |
| Power Source |
DC12V±10%, 950mA |
| Dimension |
φ142 x 142(H)mm |
| Weight |
1200g |
