ystem

Compression

Standard H.265, H.264

OS

Embedded Linux

video

Network Input

16 CH IPC input

Network Access

Bandwidth

112Mbps

Network Access

Format

8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P@25 / 30fps

Output

HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768

VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768

Audio

Network Input

16 CH IPC audio input

2-way Audio

RCA × 1

Local Output

RCA × 1

Record

Record Stream

Dual stream recording

Resolution

8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P

Mode

Manual, timer, motion, sensor

Playback

Simultaneous

Playback

Max 16 CH

Search

Time slice / time / event / tag search

Smart Search

Highlighted color to display the camera record in a certain

period of time, different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Alarm

Mode

Manual, sensor, motion, exception

Input

Support IPC alarm input

Output

Support IPC alarm output

Triggering

Record, snap, preset, e-mail, etc.

Network

Interface

RJ45 10 / 100 / 1000 Mbps × 1

PoE Port

RJ45 × 16

Protocol

TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP

Mobile

Device

OS

iOS, Andriod

Storage

HDD

SATA × 2, max 8T per HDD

Backup

Local Backup

U disk, USB mobile HDD

Network Backup

Yes

Port

USB

USB 2.0 × 2 ( one in the front panel and the other in the rear panel )

Remote

Controller

Optional

Others

Power Supply

DC48V

Consumption

≤15W ( without HDD )

Dimensions(mm )

380 × 268 × 52 ( W × D × H )

Work

Environment

-10 ～ 50 ℃，10% ～ 90% humidity
