Details
| CAMERA | |
| Image Sensor | 1/3" 2.4MP HD Aptina Sensor |
| Effective Pixels | 1920 (H) x 1080 (V) |
| Electronic Shutter | AUTO: 1/50-1/100, 000Sec (PAL) & 1/60-1/100,000Sec (NTSC) |
| S/N Ratio | ≥48dB |
| Video Output | Composite Signal (1.0Vp-p, 75Ω), Compatible with AHD, HD-TVI, HD-CVI, 960H |
| Video Frame Rate | 30fps @ 1080P |
| CAMERA FEATURES | |
| AGC | Automatic / manual |
| IR LEDs | 18 Hidden IR |
| IR LEDs Distance | 10 ~ 15M (33 ~ 49ft) |
| Day / Night | Auto (ICR) / B&W / Color |
| Noise Reduction | 2D DNR |
| BLC | Yes |
| White Balance | Auto adaptive(Range 2200～10000K) |
| WDR | N/A |
| OSD Menu | via Coaxial Cable (CoC), Compatible with Analog Mode |
| LENS | |
| Focal Lens | 3.7mm Fixed Lens |
| RECORDING | |
| Encode | CBR |
| GENERAL | |
| Power Supply | DC 12V ± 10% |
| Power Consumption | 400mA |
| Working Environment | -22ºF ~ 140ºF (-30°C ~ 60°C) |
| Dimensions | 2.7" x 4.7" x 3.3" (69 x 120 x 53mm with Bracket) |
| Weight | 0.26lbs (0.12kg) |
Dimensions
