Details
| Hardware Specifications | |
| Hardware Version | Version 3 |
| Standard | IEEE 802.3af Power over Ethernet IEEE 802.3 10Base-T IEEE 802.3u, 10/100Base-TX |
| Ethernet Connector | 2 x RJ-45 (1 for data + DC in, 1 for data out) |
| Data Rate | 10/100Mbps (vary on Ethernet device attached) |
| DIP Switch | Adjustable output DC voltage: - 5VDC (Default) - 12VDC |
| Number of Devices can be powered | 1 |
| Ethernet Cable | TIA / EIA-568, Category 5/5e cable |
| LED indicator | 1 x PoE ready / in-use |
| Dimensions (W x D x H) | 73 x 55 x 24 mm |
| Emission | FCC Class B, CE mark |
| Environment | |
| Operating | Temperature: 0~50 degrees C Relative Humidity: 5~90% |
| Storage | Temperature: -20~70 degrees C Relative Humidity: 5~90% |
