Details
| ITEM | SPECIFICATION | |
|---|---|---|
| Properties | Transmission Signal | 1 Channel |
| Transmission Distance | HD-TVI / HD-CVI / AHD Up to 250m (820ft) | |
| Category type | UTP CAT5 / 5E / 6 | |
| Video Transmission Properties and Port |
Coaxial Video Connector | BNC - M |
| Twisted- Pair Video Connector | Push - Terminal | |
| Compatible Format | HD-TVI/ HD-CVI / AHD / ANALOG | |
| Resolution | Up to 1080P HD for All Video Formats | |
| Anti -Interference | >60db | |
| Protection | TVS | Built in TVS for Surge Protection |
| Coaxial Cable Connector | 2KV(common-code) Per: IEC1000-4-5 | |
| UTP Cable Connector | 2KV(different-code)4KV(common-code) Per : IEC1000-4-5 | |
